Pole No.
|
1, 2, 3, 4
|
|
Rated voltage
|
240/415V AC
|
Rated current (A)
|
1,2,3,4,6,10,16,20,25,32,40,50,63
|
Tripping curve
|
B、C
|
|
Rated breaking capacity (Icn)
|
6000A
|
Rated frequency
|
50/60Hz
|
|
Energy limiting class
|
3
|
Rated impulse withstand voltage
|
6.2kV
|
Electro-mechanical endurance
|
6000
|
Connection terminal
|
Pillar terminal with clamp
|
Connection capacity
|
Rigid conductor up to 25mm 2
|
Fastening torque
|
2.0Nm
|
Installation
|
On symmetrical DIN rail 35mm
|
Panel mounting
|
|
